9

GB

fig.12: Recovery pulse measuring with count down (0:60 - 0:00)

fig.13: Fitness value display

fig.14: No pulse recognition (E) during recovery pulse measuring

To be noted

If no pulse value is displayed, no recovery pulse function will be

performed.

After pressing the recovery button, quickly grasp the hand pulse

sensor again since otherwise pulse measuring will be interrupted.

Home trainer

Speed calculation

60 pedal rotations per minute result in a speed of 21.3 km/h.

Kilojoule calculation

From the view of sports physicians there is the following energy

consumption during cycling: 1 hour cycling at 24 km/h requires

1680 kJ

1 kilometre results in 70 kJ

This calculation is based upon a medium training intensity and is

only changed by a variation of the pedalling frequency.

Cross trainer

Speed calculation

60 pedal rotations result in a speed of 9.5 km/h.

Kilojoule calculation

From the view of sports physicians there is the following energy

consumption during cross training: 1 hour training at 9.5 km/h re-

quires 3344 kJ

1 kilometre results in 352 kJ (with medium training intensity)

Fitness value calculation

The computer calculates and assesses the difference between load

pulse and recovery pulse and your resulting "fitness value" on the

basis of the following formula:

Note ( F ) = 6 —

(

10 x ( P1 — P2 )

)

2

P1

P1 = load pulse P2 = recovery pulse

Value 1 = very good Value 6 = unsatisfactory

The comparison of load and recovery pulse is a simple and fast

method to control your physical fitness. The fitness value is a va-

lue of orientation with regard to your ability to recover after phy-

sical load. Before you press the recovery pulse button (15) and

have the computer calculate your fitness value you should train in

your load range for a longer time, this means for at least 10 mi-

nutes. With regular cardiovascular training you will notice that

your "fitness value" will improve.

Information on pulse measuring

Pulse measuring starts when the heart in the display flashes ac-

cording to the beat of your pulse.

Pulse measurement via ear clip

Teh pulse sensor works with infrared light and measures the chan-

ges in the light transmission of the skin caused by your pulse fre-

quency. Before fitting the ear clip the ear lobe should be rubbed

10 times to stimulate blood circulation.

9.0 General

If you step in the pedals for more than 20 rotations, an automatic

display change SCAN (symbol 2 in the display) will take place in

a 5-second cycle. With the Set button you can switch it off. With

the +/– button you can then skip one display range forward or

backward.

To be noted

Distance and Speed (13) change in a 5-second-cycle.

If a preset value (except the pulse limit) is reached, it will imme-

diately be shown in the large display (10).

If you stay below 20 rotations, the electronic system will recogni-

se an interruption of training. The automatic display change will

stop, the SCAN symbol disappears, P will be displayed and the

current range remains standing still in the large display. If you do

not continue training within 4 minutes, the display will change to

room temperature (Fig. 1). In this case, the distance is added to

the total kilometres covered. All other values will not be stored.

To be noted

Distance and Speed (13) change in a 5-second-cycle.

With the +/– button you can skip one display range forward or

backward. With the Set button you get back into the input mode.

In this case, all previous training data and preset values are de-

leted.

Step on the pedals. The values will count on.

The training computer is equipped with a recovery pulse function

that enables you to measure your recovery pulse at the end of

your training.

At the end of your training press the recovery pulse button. The

computer will count down for 60 seconds and measure your pul-

se (Fig. 12). Afterwards, a fitness value with (F) is displayed (Fig.

13) the calculation of which is explained in 9.0 General. If pulse

measuring is interrupted, (E) is displayed instead of a value. If you

press the recovery button, the current training display will appear

again.

fig. 12 fig. 13

fig. 14

8.0 Recovery pulse measuring

7.0 Display after continuation of training

6.0 Display prior to training, at an interruption

of training, at the end of training

5.0 Display during training
