- 4 -

➀

➁➃➂

D5 D6 D7

Connecting the cold water supply

Connect the supply hose

(Diagram

D5

)

:

- At one end to the connection on the back of the machine

- On the other end to a tap fitted with a threaded end 20mm dia. x 27

(3/4 BSP).

If you use a self-piercing tap, the useful aperture must have a

minimum diameter of 6mm.

Water supply:

- Minimum water pressure: 0.1 MPa or 1 bar

- Maximum water pressure: 1 MPa or 10 bars

Draining away the waste water

Fit the hose bracket provided inside your machine to the end of the drain

hose and then connect the hose

(Diagram

D6

)

:

• Either, temporarily, over a sink or a bathtub.

• Or permanently to a ventilated U-bend.

If your installation does not have a ventilated U-bend, check that the

connection is not sealed. In fact, to avoid any waste water flowing

back into the machine, you are strongly recommended to leave an air

gap between the machine’s drain hose and the drainpipe.

In any case, the drain hose bracket must be placed at a height of 65 to

90cm higher than the base of the machine.



Ensure that the drain hose is tied firmly in place with cord to avoid

the bracket coming loose during draining and causing a flood.

The waste water can be drained away to the ground provided that the

drain hose passes through a point 65 to 90cm higher than the base of

the machine

(Diagram

D7

)

.



For your safety, you must comply with the instructions below.

Electrical supply

• Before connecting your machine, you must ensure that your

installation’s electrical characteristics match those of your machine

(see the details provided on the information plate affixed to the back

of the machine).

• The electrical installation must comply with the prevailing standards

and the Electricity Board’s regulations in the country concerned,

particularly as regards Earthing and installation in shower rooms.

We cannot be held responsible for any incident caused by the

machine being incorrectly earthed.



Advice on the electrical installation of your machine

• Do not use an extension lead, adapter or multiple socket.

• Never cut out the Earth wire.

• The socket must be readily accessible but out of the reach of children.

If in any doubt, please contact your installer.

Connecting your machine

see diagrams

D5-D6-D7

Your machine conforms to European Directives EEC/73/23 (Low

Voltage Directive) and EEC/89/336 (Electromagnetic Compatibility)

as modified by Directive EEC/93/68.



On any new installation (following a move or resale, etc.), the

machine must be connected using new hoses. The old hoses must

not be reused.

Loading your washing

Before your first wash

Before making your first wash, we recommend that you carry out

a “COTTON 90 wash without pre-wash” and with no washing in the

drum, using a 1/2 measure of your usual detergent in order to

eliminate any residues from manufacturing that may remain in your

machine.

Perform these actions in the following order:

Open the machine

• Check that the “On/Off” button is released.

• Depending on the model, lift the opening handle or press the push

button on the front of the machine.

The lid will open.

• Open the drum by pressing the button on the front door.

Insert your washing

For optimum washing performance, place your washing, preferably

sorted and folded, in the drum, distributing it evenly without heaping it

up. Mix large and small items to obtain an optimum, well-balanced spin.

Close the drum

Ensure that the drum is correctly closed.



Check that the three hooks and the border of the button are fully

visible.

I / O

Loading the washing products

Dispensing the detergent

The amount of detergent to be used depends on the hardness of the

water, the extent to which your washing is soiled and the amount of

washing to be washed.

Please refer to the dosing instructions on your pack of detergent.

Warning: in most cases, the detergent manufacturer’s recommendations

apply to the drum filled to the maximum. Adjust the dosage correctly to

the weight of the washing you have placed in the machine.

These recommendations will help you to avoid using too much detergent,

which causes foam to be produced. Too much foam can reduce your

machine’s performance and increase the length of the washing cycle

and the consumption of water.

Detergents for woollens and delicate fabrics

You are recommended to use an appropriate detergent for washing

these fabrics (avoid placing such detergents directly on the drum because

they have an aggressive action on the metal).



The “WASH” container may contain powder or liquid but liquid

detergent should not be used for programmes WITH

Pre-wash

and/or WITH

“Delayed Start” (depending on the model).



Concentrated softener should be diluted with warm water.



Concentrated bleach must be diluted.



To fill the product containers correctly, place the lid fully open.



Do not exceed the MAX level.

➀

Pre-wash container

(powder)

➁

Wash container

(powder or liquid)

➂

Softener

➃

Bleach

cl

:

POWDERED

DETERGENT

:

LIQUID

DETERGENT
