- 3 -

Contents

Page

Removing the transport clamps from your machine ..........................3

Installing your machine ............................................................................3

Connecting your machine ........................................................................4

Loading your washing ..............................................................................4

Loading the washing products................................................................4

Programming ......................................................................................5 & 6

Automatic safety devices ........................................................................6

Page

Details of fonctions ..................................................................................7

Modifying a washing programme............................................................7

Incidents that may occur..........................................................................8

Automatic fault diagnostics ....................................................................8

Running maintenance ..............................................................................9

Cleaning the pump filter ..........................................................................9

D2 D3

13

1

1

2

2

a

b

a

b

➀

➁

➀

➁

➃

➂

D1

D4

A

C

B

E

F

G

D

D

Removing the transport clamps from your machine

see diagrams

D1-D2-D3

1 - Remove the washing machine from its plinth (check that the wedge



supporting the motor is not still inserted in the machine) (

Diagram

D1.➀

)

2 - Remove the 4 screws



with a screwdriver

(Diagram

D1.➁

)

3 - Remove the cross clamp



by removing the 2 screws



(Diagram

D1.➂

)

using a 10 or 13mm spanner (depending on the model). (Ensure

that you remove the two plastic braces fixed on the cross clamp

at the same time as the clamp itself).

Replace the screws



in their initial positions.

4 -



You must block off the two holes using the hole covers provided



(supplied in the accessories bag)

(Diagram

D1.➃

)

5 - Remove the drum-tank assembly locking wedge

(Diagram

D2

)

.

To do this:

- Lift the lid on the machine

- Remove wedge



- Remove wedge



by turning it a quarter turn

- Release the drum doors, locked in the lower position, by pressing

down on both eaves simultaneously.

6 -



Remove the pipe support collars

➀

You must block off the

holes revealed with the hole covers

➁

supplied in the accessories

bag

(Diagram

D3

)

.

Installing your machine

see diagram

D4



BEFORE USING THE MACHINE IN ANY WAY, YOU MUST FIRST PERFORM THE FOLLOWING OPERATIONS.

These comprise removing all the components designed to immobilise the drum in your machine during transport.

These so-called “releasing” operations are necessary for your machine to operate correctly and to conform to the prevailing safety

standards.

If they are not carried out completely, this could cause severe damage to your machine while it is operating.



We would recommend that you keep all the locking components since

these must be refitted if you must subsequently transport your machine

again.

All these components, just like all the components in your machine,

are made of recyclable materials and it is useful to bear this in mind

when you eventually come to dispose of your machine at the end of

its useful life.



Your machine has been scrupulously checked before it left the factory.

You may therefore notice a little water still remaining in the tank or the

products box.

Mounting it on castors:

If your machine is equipped with removable castors, you will be able

to move it quite easily.

To mount it on castors, swivel the lever on the bottom of the machine

from the right to the far left

(Diagram

D4

)

.



The machine must not rest on the “front” castors while it is

operating: remember to return the lever to its initial position.

Levelling the machine:

Use a spirit level to check that the floor is horizontal: maximum slope

2°, i.e. a discrepancy of approximately 1cm over the width and of

1.5cm over the depth of the machine.

Your machine’s surroundings:



If you are installing your machine next to another machine or a unit,

we recommend that you leave a gap between them to allow for air

circulation.



We also strongly recommend that you do NOT:

- Install your machine in a damp, poorly ventilated room.

- Install your machine in an area where it could be subject to water

splashes.

- Install your machine on a carpeted floor.

If you cannot avoid doing this, please take every precaution to avoid

blocking air circulation at the bottom of the machine in order to

ensure that the internal components are well ventilated.
