2

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.whirlpool.eu/docs and parts-selfservice.europeanappliances.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-

sales Service, please state the codes provided on your product‘s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model

identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

:

400011662599C

09/2024 ks - Xerox Fabriano

DELAY - The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

HALF LOAD - If there are not many dishes to be washed, a half load-

ing may be used in order to save water, electricity and detergent.

Remember to halve the amount of detergent.

Please scan the QR code on your product in order to have more detailed information.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address: dw_test_suppor[email protected]om

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

A

A

B

C

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

CUTLERY BASKET

The basket is equipped with top grilles for improved

cutlery arrangement. The cutlery basket should be

positioned only at the front of the lower rack.

Knives and other utensils with sharp edges

must be placed in the cutlery basket with the

points facing downwards or they must be posi-

tioned horizontally in the tip-up compartments

on the upper rack.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

UPPER RACK

(loading example for the

upper rack)

Load delicate and light

dishes: glasses, cups,

saucers, low salad bowls.

LOWER RACK

(loading example for the lower rack)

For pots, lids, plates, salad bowls, cutlery etc.. Large

plates and lids should ideally be placed at the sides

to avoid interferences with the spray arm. The low-

er rack has tip-up supports which can be used in

a vertical position when arranging plates or in a

horizontal position (lower) to load pans and salad

bowls easily.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

KEYLOCK - A long press (for 3 seconds) of HALF LOAD button, will

activate the KEYLOCK function. To deactivate the KEYLOCK, long press again.

WATER TAP CLOSED – Alarm

Flashes when there is no inlet water or water tap is closed.

DRAIN OUT - To stop and cancel the active cycle, the Drain Out

function can be used. A long press of START/PAUSE button, will

activate the DRAIN OUT function. The active program will be stopped and

the water in the dishwasher will be drained out.

®/TM/ © 2024 Whirlpool, Produced under license
