Congratulations!

You have chosen to purchase a high-quality

product. Familiarise yourself with the product

before using it for the first time.

Read the following operating

instructions carefully.

Use the product only as described and only

for the given areas of application. Store these

operating instructions carefully. When passing

the product on to third parties, please also hand

over all accompanying documents.

Package contents (Fig. A)

1 x heating thermostat (1) incl.

union nut (1a)

display (1b)

battery indicator (1c)

‘Menu’ button (1d)

‘OK’ button (1e)

dial (1f)

‘Time’ button (1g)

holiday function (1h)

manual mode display /

automatic mode display

(1i)

heating temperature display

/

economy temperature

(1j)

heating times (clock times) (1k)

open window detection (1l)

‘day/block’ display (1m)

1 x Danfoss RA adapter (2a)

1 x Danfoss RAV adapter (2b)

1 x Danfoss RAVL adapter (2c)

1 x tappet extension (3)

1 x support ring (4)

1 x spacer ring 0.5mm (5a)

1 x spacer ring 1.0mm (5b)

1 x screw (6)

1 x screw nut (7)

2 x battery (1.5V LR6, AA) (8)

1 x quick guide

1 x operating instructions

Technical data

Dimensions: approx. 95 x 59 x 60mm

(L x W x H)

Power supply battery:

2 x 1.5V LR6, AA

Supply voltage: 3V

Current consumption: max. 100mA

Protection class: IP20

Ambient temperature: 5–55°C

Connection: M30 x 1.5mm

Actuating force: > 65N

Running noise: < 40dB(A) at a distance of 30cm

Symbol for direct voltage

UK Conformity Assessed

Delta-Sport Handelskontor GmbH here-

by declares that this product meets the

following basic requirements, as well as

other important regulations:

Electromagnetic Compatibility Regulations 2016

The Restriction of the Use of Certain Hazardous

Substances in Electrical and Electronic Equip-

ment Regulations 2012

Delta-Sport Handelskontor GmbH

hereby declares that this product meets

the following basic requirements, as

well as other important regulations:

2014/30/EU – EMC Directive

2011/65/EU – RoHS Directive

Date of manufacture (month/year):

06/2023

Intended use

The product moves a radiator valve to regulate

the room temperature. It can be mounted on all

common radiator valves. The product is for pri-

vate indoor use only and not for commercial use.

FOR INDOOR USE ONLY.

Safety information

• Important: read these operating instructions

carefully and keep them for future reference!

• This product can be used by

children above the age of 8

and by people with reduced

physical, sensory, or mental

capacities or by those lacking

experience and knowledge

provided they are supervised

or have been instructed in the

safe use of the product and

understand the risks involved.

Children may not play with

the product. Cleaning and

user maintenance may not be

performed by children without

supervision.

Danger to life!

• Never leave children with the packaging

materials unsupervised. There is a risk of

suffocation.

Risk of injury to children!

• Children must not play with the product. In

particular, point out to children that the prod-

uct is not a toy.

• Bear in mind children’s natural instinct for play

and eagerness to experiment. Prevent situa-

tions and behaviours that are not intended for

the product.

• The product must be stored out of reach of

children when not in use.

Risk of injury!

• Check the product for damage or wear and

tear before each use. Use the product only if it

is in perfect condition!

• Do not open the product. It does not contain

any user-serviceable parts.

• Never carry out repairs yourself.

• Repairs to the product may be carried out by

qualified personnel only.

Warnings on batteries!

• Remove the batteries if they are empty or if

the product is not going to be used for an

extended period.

• Do not use different battery types or brands,

new and used batteries in combination, or

batteries with different capacities, as they leak

and can thus cause damage.

• Observe the polarity (+/-) when inserting

batteries.

• Change all batteries at the same time and

dispose of the old batteries properly.

• Warning! Batteries may not be charged or

reactivated in any way. They may not be dis-

mantled, thrown into fire, or short-circuited.

• Always keep batteries out of the reach of

children.

• Do not use rechargeable batteries!

• The cleaning and user-maintenance may not

be carried out by children without supervision.

• Clean the batteries and the device contacts as

necessary and before inserting the batteries.

• Do not expose the batteries to extreme condi-

tions (e.g. direct sunlight). Otherwise there is

an increased risk of leaks.

• Warning. Dispose of used batteries imme-

diately. Keep new and used batteries out

of the reach of children. Seek medical help

immediately if you suspect that batteries have

been swallowed or ingested.

Danger!

• Handle a damaged or leaking battery with

extreme care and dispose of it properly and

immediately. Wear gloves to handle the

battery.

• If you come into contact with battery acid then

wash the affected area with soap and water.

If battery acid gets in your eye rinse it out with

water and seek medical help immediately!

• Do not short-circuit the terminals.

Inserting/replacing batteries

(Fig. B)

WARNING! Comply with the following

instructions in order to prevent mechani-

cal and electrical damage.

For inserting and replacing the batteries (8)

proceed as shown in Fig. B.

Note: pay attention to the plus/minus polarity

of the batteries and their correct installation. The

batteries must be located entirely inside the bat-

tery compartment.

Note: when changing a battery, all your

personal settings will be deleted.

Assembly

CAUTION

Risk of burns!

• Allow the radiator to cool down before assem-

bling, disassembling or troubleshooting.

• Wear working gloves.

Note: the product can be assembled without

draining heating water or interfering with the

heating system. Switching off the heating or spe-

cial tools is not necessary. The union nut (1a) fits

radiator valves with thread size M30 x 1.5mm.

GB
