children - risk of suocation. The appliance must be

disconnected from the power supply before any

installation operation - risk of electrical shock. During

installation, make sure the appliance does not damage

the power cable - risk of re or electrical shock. Only

activate the appliance when the installation has been

completed.

WARNING: Modication of the appliance and its

method of installation are essential in order to use

the appliance safely and correctly in all the additional

countries.

Use pressure regulators suitable for the gas pressure

indicated in the instruction.

The room must be equipped with an air extraction

system that expels any combustion fumes.

The room must also allow proper air circulation, as

air is needed for combustion to occur normally. The

ow of air must not be less than 2 m

3

/h per kW of

installed power.

The air circulation system may take air directly from

the outside by means of a pipe with an inner cross

section of at least 100 cm

2

; the opening must not be

vulnerable to any type of blockages.

The system can also provide the air needed for

combustion indirectly, i.e. from adjacent rooms tted

with air circulation tubes as described above. However,

these rooms must not be communal rooms, bedrooms

or rooms that may present a re hazard.

Liquid petroleum gas sinks to the oor as it is heavier

than air. Therefore, rooms containing LPG cylinders

must also be equipped with vents to allow gas to escape

in the event of a leak. As a result LPG cylinders, whether

partially or completely full, must not be installed or

stored in rooms or storage areas that are below ground

level (cellars, etc.). It is advisable to keep only the cylinder

being used in the room, positioned so that it is not

subject to heat produced by external sources (ovens,

replaces, stoves, etc. ) which could raise the temperature

of the cylinder above 50°C.

Should you experience diculty in turning the burners knobs, please contact

After Sales Service for replacement of the burner tap if found to be faulty.

The openings used for the ventilation and dispersion of heat must never be

covered.

Carry out all cabinet cutting works before tting the

appliance in the furniture and remove all wood chips

and sawdust.

If the appliance is not installed above an oven, a

separator panel (not included) must be installed in the

compartment under the appliance.

GAS CONNECTION

WARNING: Prior to installation, ensure that the local

distribution conditions (type of gas and gas pressure)

and the adjustment of the appliance are compatible.

Check that the pressure of the gas supply is consistent

with the values indicated in “Burner and nozzle

specications” table.

WARNING: The conguration conditions for this

appliance are stated on the label (or data plate).

WARNING: This appliance is not connected to a

combustion products evacuation device. It must be

installed and connected in accordance with current

installation regulations. Particular attention must be

paid to the relevant requirements regarding ventilation.

If the appliances is connected to liquid gas, the

regulation screw must be fasted as tightly as possible.

IMPORTANT: When the gas cylinder or gas container is

installed, it must be properly settled (vertical orientation).

WARNING: This operation must be performed by a

qualied technician.

Use only exible or rigid metal hose for gas connection.

Connection with a rigid pipe (copper or steel)

Connection to the gas system must be carried out in

such a way as not to place any strain of any kind on the

appliance. There is an adjustable L-shaped pipe tting

on the appliance supply ramp and this is tted with a

seal in order to prevent leaks. The seal must always be

replaced after rotating the pipe tting (the seal is

provided with the appliance). The gas supply pipe

tting is a threaded 1/2 gas cylindrical male attachment.

Connecting a exible jointless stainless steel pipe to

a threaded attachment. The gas supply pipe tting is a

threaded 1/2 gas cylindrical male attachment. These

pipes must be installed so that they are never longer

than 2000 mm when fully extended. Once connection

has been carried out, make sure that the exible metal

pipe does not touch any moving parts and is not

compressed. Only use pipes and seals that comply

with current National regulations.

IMPORTANT: If a stainless steel hose is used, it must

be installed so as not touch any mobile part of the

furniture (e.g. drawer). It must pass through an area

where there are no obstructions and where it is possible

to inspect it on all its length.

The appliance should be connected to the main gas

supply or to gas cylinder in compliance with the current

national regulations. Before making the connection,

make sure that the appliance is compatible with the gas

supply you wish to use. If this is not the case, follow the

instructions indicated in the paragraph “Adapting to

dierent types of gas”.

After connection to the gas supply, check for leaks

with soapy water. Light up the burners and turn the

knobs from max position 1* to minimum position 2* to

check ame stability.

ADAPTING TO DIFFERENT TYPES OF GAS

(This operation needs to be carried out by a qualied

technician).

In order to adapt the appliance to a type of gas other

than the type for which it was manufactured (indicated

on the rating label), follow the dedicated steps provided

after installation drawings.

ELECTRICAL WARNINGS

IMPORTANT: Information about current and voltage

consumption is provided on the rating plate.
