ENQuick Guide

1

THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive a more complete assistance, please register

your appliance on: www.indesit.com/register

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher

(see PRODUCT DESCRIPTION) and must be lled when the SALT REFILL

indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Only the rst time you do this: ll the salt reservoir

with water.

3. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse

aid dispenser A should be lled when when

the dark optical indicator on the dispenser

door C becomes transparent.

NEVER pour the rinse aid directly into the

appliance tub.

D

E

A

C

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device D. Introduce the

detergent into the dry dispenser E only. Place the amount of detergent for

pre-washing directly inside the tub.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently

pre-

venting scale buildup on heater, contributing also to better cleaning

eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

CONTROL PANEL

FIRST TIME USE

Before using the appliance carefully read Safety Instructions

guide.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address:

dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Values given for programmes other than the eco programme are indicative only. The actual time may vary depending on many factors such as temperature

and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor

calibration. The sensor calibration can increase program duration up to 20 min.

PROGRAMS TABLE

1 2 4 53

1. ON-OFF / Reset button with indicator light

2. Program selection button / Push&GO

3. Salt rell indicator light

4. Program indicator lights

5. START/Pause button with indicator light

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

Program Programs description

Drying

phase

Duration

of wash

program

(h:min)

*)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

1.

Eco 50°- Eco program is suitable to clean normally soiled tableware, that

for this use, it is the most ecient program in terms of its combined ener-

gy and water consumption, and that it is used to assess compliance with

the EU Ecodesign legislation.

3:35 9.5 0.95

2.

Intensive 65° - Program recommended for heavily soiled crockery, espe-

cially suitable for pans and saucepans (not to be used for delicate items).

2:40 18.0 1.60

3.

Mixed 55° - Mixed soil. For normally soiled dishes with dried food residues. 2:15 16.0 1.40

4.

Fast&Clean 28’

50° -

Program to be used for half load of lightly-soiled

dishes with no dried food residues. Does not have drying phase.

-

0:28 9.0 0.50

5.

Push&GO 50° - Everyday wash and dry cycle that ensures great cleaning

performance in a short time without the need to pre-treat dishes.

1:30 11.5 1.30

PUSH&GO

Push&GO button (P) is an easily distinguishable button that allows you direct access to the Push&GO program, a wash and dry cycle that ensures great

cleaning performance in a short time. You don’t have to worry which program to choose, Push&GO cycle will do the work for you.

To select Push&GO program, switch on appliance, press only P button for 3 seconds (corresponding indicator lights up) and close the door within 4 seconds.
