PCE Akku LED 500
Operation manual
Use the lamp only for the purpose it is designed for: as a lamp for illumination in dark
areas/outdoors.
Any other use of the lamp can cause damage to the lamp or cause hazard to the user and
itsenvironment(electricalshocks,re,shortcircuit,etc...)
Before use, rst read the Safety Instructions:
• The lamp is IP54 rated (protected against dust and splashing water)
• Protect batteries from extreme cold, heat and vibrations. Due to this, batteries can
signicantlyreduceincapacityorevenmalfunction.
• Always charge the lamp indoors, above 0 °C, and do not cover it during charging!
• Do not expose the lamp to temperatures exceeding 40 °C
• Always use supplied chargers. When using other chargers the lamp can malfunction.
Any warranty becomes void when using non-original chargers,
• Should the lamp malfunction, do not open, but have it checked by the importer, other-
wise any warranty on the product becomes void.
• Never disassemble the battery! Should the battery leak, avoid any contact with skin
and eyes. Rinse skin with water and soap. Rinse eyes thoroughly and consult a doctor.
• Itisprohibitedtomodifythe lamp inanyway;otherwiseanywarranty on thelamp
becomes void.
• Never shine the LED lamp directly into the eyes, this can cause eye injuries.
• Never charge the LED lamp if cables or the plug of the charger is/are damaged, always
buy new original chargers.
The importer accepts no liability for damage or consequential damage to persons or prop-
erty caused by failure to observe the above safety instructions.
Operating instructions:
• Charging should take place indoors, chargers are not splash proof, the area where
charging is performed must be well ventilated.
• First, connect the charger with the cable to the charging socket at the rear of the lamp,
only then connect to the mains!
• Chargeatleast6-8hoursforthersttime,whilechargingalwaysswitchothelamp.
• Preferably charge at room temperature, this takes the shortest time and is also better
for battery life.
• Thelampcanbecomewarmduringcharging(alwaysswitchothelampduringcharg-
ing)
• When charging of the lamp, the LED indicator on the lamp will be red, when it is fully
charged after about 3,5 hours, the LED indicator will be green (full).
• Whenthelampisfullycharged,rstdisconnectthechargerfromthemains,andthen
remove the cord of the charger from the lamp.
• Theon/oswitch(button)islocatedatthefrontofthelamp.Bymeansofthisbutton
youcanswitchon/otheashlightandportablelampfunction.
• Beforebatteryisrunningout,thelampashesseveraltimes.AfterthatthefrontLED
indicatesredlight.Thelampisstilllitby100%,butwithredashingLED!
• The lamp shuts down completely after a couple of minutes.
• Afterresettingashlight-function,itworksforapprox.10minutesinordertoleavea
dark room.
• Always store the lamp indoors, preferably at room temperature. The service life of the
batteries will then remain optimal.
• If the lamp is not used, charge at least 1 time per 3 months (preservation of the battery).
When using the LED lamp:
• The lamp can be suspended by means of integrated hook.
• The lamp can be hanged to the belt by means of a clip.
• The lamp has a powerful magnet in the support (three positions), so you can hang the
lampindierentpositionstometalobjects.
During maintenance:
• The lamp may not be charged!
• No aggressive cleaning detergents may be used.
• Clean the lamp preferably with a damp cloth (do not hold lamp under the water tap or
submerge)
After end of life:
• The lamp must not be disposed of with regular waste. The lamp should be taken to a
collection point (municipality) or the supplier. They must ensure that the lamp is pro-
cessed environmentally friendly.
Technical specications:
Lamp: 10+1 Ultra High power LED (SMD)
500 lumens (lamp)
120lumens(ashlight)
Battery: Lithium-ion 3.7V - 4400 mAh
Operatingtime: approx.4,5hours(lamp)/approx.17(ashlightmode)
Charging time: approx. 3,5 hours
Charger: 12-24V DC and 100-240V AC 50/60 Hz and USB connector
Charging: LED green (full) - red (charging)
Switch: Twofunctions10LEDs(lamp)/1LED(ashlight)
Protection class: 2/3
Enclosure (lens): Impact-resistant polycarbonate
Protected: Against overcharging and fully discharge
On Operation:
• Chargeatleast6-8hoursforthersttime(switchothelamp)
• If the lamp is not used, charge at least 1 time per 3 months
• If red LED (on lamp) is on, then charge
Adhere to the above points. We are not liable for damage due to incorrect use,
because any deviation from this by you, will void any warranty of manufacturer,
supplier or importer and the legal entities referred to above will not be respon-
sible for any damage, injury or re, etc. caused by this lamp.
CE Declaration
This product complies with the following provisions and guidelines:
RoHS 2011/65/EU - EMV 2014/30/EU - LVD 2014/35/EU.
No guarantee for technical changes or printing errors.
PC Electric GmbH
Diesseits 145 | AT-4973 St. Martin/Innkreis
Phone +43 (0) 77 51/61 220
Fax +43 (0) 77 51/69 69
