Cantilever Parasol

Q

Introduction

Before using the product for the first time, take time to familiarise

yourself with the product first. Read the following assembly instruc-

tions and safety instructions carefully. Only use the product as

described and for the designated areas of application. Please keep these

instructions in a safe place. If you hand this product on to a third party, you

must also pass on all documents relating to the product.

Q

Intended Use

This article is intended for providing protection from the sun in outdoor

domestic environments only. Any use other than previously mentioned or any

product modification is prohibited and can lead to injuries and / or product

damage. The manufacturer is not liable for any damages caused by any use

other than for the intended purpose. The product is not intended for commer-

cial use.

Q

Description of parts

1

Cross member for paving stand 1

2

Cross member for paving stand 2

3

Bottom pole section

4

Bolt (approx. M8 x 20 mm)

5

Plain washer (approx. ø 8 mm)

6

Top pole with attachments

7

Arm

8

Umbrella top

9

Top pole section

10

Stopper (top pole section)

11

Locking knob

12

Handle

13

Union nut

14

Crank

15

Crankcase

16

Support rod

17

Plastic sleeve

18

Stopper (arm)

Q

Included in delivery

Please check immediately on unpacking that the delivery is complete and

that the product and all parts are in perfect condition. Do not under any

circumstances assemble the product if the delivery is incomplete.

1 x Cross member for paving stand 1

1 x Cross member for paving stand 2

1 x Bottom pole section

4 x Bolt (approx. M8 x 20 mm)

4 x Plain washer (approx. ø 8 mm)

1 x Top pole with attachments

1 x Assembly instructions manual

Q

Technical data

Dimensions

Hanging umbrella: Approx. 300 x 258 cm (ø x H)

Paving stand: Approx. 100 x 100 cm (L x W)

Safety advice

PLEASE READ THE ASSEMBLY INSTRUCTIONS BEFORE USE! PLEASE

KEEP THE ASSEMBLY INSTRUCTIONS IN A SAFE PLACE!

J

WARNING! DANGER TO LIFE AND RISK OF

ACCIDENTS TO INFANTS AND CHILDREN! Never leave

children alone and unsupervised with packaging material and

the product. The packaging material constitutes a risk to life through suffoca-

tion and strangulation. Children often underestimate the risks. Always

keep children away from the product. The product is not a toy.

m CAUTION! RISK OF INJURY! Ensure that all parts are undamaged

and have been assembled appropriately. Risk of injury exists if assembled

incorrectly. Damaged parts can effect safety and function.

m CAUTION! Do not leave children unattended. The product is not a

climbing frame or toy. Make sure that nobody climbs or leans on the

product, particularly children. The product could become imbalanced

and tip up. This may result in injury and / or damage.

m CAUTION! DANGER OF TIPPING OVER! Ensure that the product

stands in stable equilibrium on a firm surface. The hanging umbrella must

always be used in conjunction with 4 pieces of approx. 50 x 50 cm

paving slabs (not included). Otherwise the hanging umbrella could tip

over and result in injury and damage to property.

J Never move the hanging umbrella in the open state. Always fully close

the umbrella top

8

first and pull in the arm

7

completely. Otherwise

the load on the product could become unbalanced and cause it to

overturn, resulting in injury and / or damage.

h CAUTION!

FIRE HAZARD!

Never place the product near an open fire

and / or radiant heaters.

J Make sure that this product is standing on a solid, level surface.

J Make sure the product is stable before use!

m CAUTION! RISK OF INJURY! Before opening and closing the

product, make sure that there are no people standing too near to it.

m CAUTION! RISK OF CRUSHING! Watch your fingers when opening

and closing the product. If you are careless, you risk injuring your fingers

by crushing them!

J Ensure that the top pole with attachments

6

is attached firmly to the

lower pole section

3

on the paving stand. Unless this is done, it is not

safe to use the hanging umbrella.

J

Close the hanging umbrella if the wind shows signs of increas-

ing in speed or on the approach of squally showers.

J Never use the product as protection against bad weather.

J Never leave an open hanging umbrella unattended. Damage could

occur if strong winds arise unexpectedly.

J Close the hanging umbrella in the event of wind, snow or rain.

J Do not hang any objects (e.g. clothing) from the product.

Q

Assembly / disassembly

Note: For assembly you will need a working space at least 16 m

2

in area

and 4 m in diameter.

Note: If possible have a second person help you with the assembly.

Note: Keep 4 pieces of approx. 50 x 50 cm paving slabs close at hand for

the paving stand. Place the paving slabs evenly on the cross members of the

paving stand.

Q

Assembling the paving stand

j Fit the cross member for paving stand 2

2

on top of the cross member

for paving stand 1

1

(see Figure B).

j Bolt the bottom pole section

3

to the assembled cross members. Use

the bolts (approx. M8 x 20 mm)

4

with the plain washers

(approx. ø 8 mm)

5

(see Figure C).

j Insert the top pole with attachments

6

into the bottom pole section

3

attached to the paving stand and screw the two poles together with the

union nut

13

(see Figure D, step

1

).
